Design | Mid High |
Impedance | 4 |
Power Handling (AES) | 200 Watts (continuous) |
Maximum Power Handling (AES) | 400 Watts (program) |
Sensitivity 2.83V / 1m | 98 dB |
Maximum SPL | 121 dB (cont. max SPL / 1m) |
Frequency Response | 155 Hz - 11 kHz |
Dispersion | 10° x 120° |
SYSTEM OPERATION | |
Recommended Amplification | 200 - 400 Watts |
System Controller | - |
Speaker Cables | Min 2 x 2.5 mm2, Preferred 2 x 4 mm2 |
PRODUCT FEATURES | |
Components | 8 x 4.5" Driver |
Crossover | - |
Connectors | Speakon. |
Dimensions (H x W x D) | 1000 mm x 160 mm x 160 mm |
Weight (kg) | 13 |
Shipping Weight (kg) | 14 |
colour | Black, white |
Options | Available in Ral colours on request |
Rigging | 2 x M8 mounting points for installation brackets, or tilt and turn hardware |
HARDWARE | |
Fitted as standard | - |
Optional | HWB - Horizontal Wall Bracket |
Additional Descriptive Data | Aluminium Extrusion, powder coated with kick-proof steel grill finished with stainless steel Ohm |
